Public Member Functions | Protected Attributes
cogip::cogip_defs::Coords Class Reference

Absolute coordinates along X and Y axis. More...

Detailed Description

Absolute coordinates along X and Y axis.

Definition at line 21 of file Coords.hpp.

#include <Coords.hpp>

+ Inheritance diagram for cogip::cogip_defs::Coords:
+ Collaboration diagram for cogip::cogip_defs::Coords:

Public Member Functions

 Coords (double x=0.0, double y=0.0)
 Constructor. More...

 Coords (const PB_Coords &coords)
 Constructor from Protobuf class.

double x (void) const
 Return X coordinate.

double y (void) const
 Return Y coordinate.

void set_x (double x)
 Set X coordinate. More...

void set_y (double y)
 Set Y coordinate. More...

double distance (const Coords &dest) const
 Compute the distance the destination point. More...

bool on_segment (const Coords &a, const Coords &b) const
 Check if this point is placed on a segment defined by two points A,B. More...

bool operator== (const Coords other) const
 Check if this point is equal to another. More...

void pb_copy (PB_Coords &coords) const
 Copy data to Protobuf message. More...


Protected Attributes

double x_
 x-position

double y_
 y-position


Constructor & Destructor Documentation

◆ Coords()

cogip::cogip_defs::Coords::Coords ( double  x = 0.0,
double  y = 0.0
)
inline

Constructor.

Parameters
[in]x[in] X coordinate
[in]y[in] Y coordinate

Definition at line 24 of file Coords.hpp.

+ Here is the caller graph for this function:

Member Function Documentation

◆ distance()

double cogip::cogip_defs::Coords::distance ( const Coords &  dest) const

Compute the distance the destination point.

Parameters
[in]dest[in] destination

◆ on_segment()

bool cogip::cogip_defs::Coords::on_segment ( const Coords &  a,
const Coords &  b
) const

Check if this point is placed on a segment defined by two points A,B.

Returns
true if on [AB], false otherwise
Parameters
[in]a[in] point A
[in]b[in] point A

◆ operator==()

bool cogip::cogip_defs::Coords::operator== ( const Coords  other) const
inline

Check if this point is equal to another.

Returns
true if points are equal, false otherwise
Parameters
[in]other[in] point to compare

Definition at line 62 of file Coords.hpp.

◆ pb_copy()

void cogip::cogip_defs::Coords::pb_copy ( PB_Coords &  coords) const
inline

Copy data to Protobuf message.

Parameters
[out]coords[out] Protobuf message to fill

Definition at line 67 of file Coords.hpp.

◆ set_x()

void cogip::cogip_defs::Coords::set_x ( double  x)
inline

Set X coordinate.

Parameters
[in]x[in] new X coordinate

Definition at line 39 of file Coords.hpp.

+ Here is the call graph for this function:
+ Here is the caller graph for this function:

◆ set_y()

void cogip::cogip_defs::Coords::set_y ( double  y)
inline

Set Y coordinate.

Parameters
[in]y[in] new Y coordinate

Definition at line 44 of file Coords.hpp.

+ Here is the call graph for this function:
+ Here is the caller graph for this function:
The documentation for this class was generated from the following file:
